DYNAMIC B2G 35.46.01

DYNAMIC B2G 35.46.01

We are sorry, but this model has been sold out and cancelled from our product range.

DYNAMIC fireplace inserts with double and triple glazing and back stoking meet all the requirements of modern buildings. You can stoke from a different room and thus achieve maximum user comfort.

DYNAMIC fireplace inserts are well suited for low-energy houses thanks to their double and triple glazing. The back stoking door allows you to comfortably add wood to the combustion chamber. The glass in the doors includes a design print. Fireplace inserts are equipped with an EAI (external air intake) system and designed for accumulation as well as convection operation. The combustion chamber is lined with chamotte bricks and a hinged iron grate with an ash tray. Secondary air intake washes over the glass in the door to prevent the cumulation of deposits. Primary and secondary air intake is regulated by a single control element. A MAMMOTH side accumulation set and upper accumulation rings can be purchased separately for fireplace inserts, which can extend the period of heat radiation by more than 12 hours. The innovative DOUBLE SPIN flue gas system increases efficiency and reduces the environmental impact of the fireplace insert.

  • Technical parameters
  • Accessories
  • Alternative products
  • Download
Technical parameters
  • [RS: Výška] 990 [RS: mm]
  • [RS: Šířka] 514 [RS: mm]
  • [RS: Hloubka] 492 [RS: mm]
  • [RS: Výška dvířek] 426 [RS: mm]
  • [RS: Šířka dvířek] 305 [RS: mm]
  • [RS: Hmotnost] 140 [RS: kg]
  • [RS: Regulovatelný výkon] 2,0-6,0 [RS: kW]
  • [RS: Průměr kouřovodu] 150-200 [RS: mm]
  • [RS: Průměr kouřového hrdla] 200 [RS: mm]
  • [RS: Průměr centr. přív. vzduchu (CPV)] 125 [RS: mm]
  • [RS: Provozní tah] 12 [RS: Pa]
  • [RS: Účinnost] 80,3 %
  • [RS: Průměrná spotřeba dřeva] 1,1 [RS: kg/h]
