HEAT 2g 70.44.01 - straight fireplace insert
Front Steel–cast iron combination Hot air (conventional) Accumulative Double spin Hinge door

HEAT 2g 70.44.01 - straight fireplace insert

order code: H2P 01

•  Romotop DOUBLE SPIN special flue gas system
•  ready for an external connection of the combustion air intake (EAI)
•  intended for convection as well as accumulation operation
•  cast iron grate
•  ash pan
•  chamotte combustion chamber
•  adjustable legs
•  glass with printed decor
•  door frame made of special rigid rolled profile
•  build-up dimensions: 699 x 438 mm
•  construction frame may be added
•  log length 500 mm
•  complies with the following standards: EN 13 229, DIN+, 15a B-VG as of 2015, Bimsch V 1/2, Czech Republic Clean Air Act

icon-scales


Casing

black

Technical parameters

Height 902 mm
Width 699 mm
Depth 490 mm
Door height 407 mm
Door width 664 mm
Weight 168 kg
Regulated output 4,5-11,7 kW
Smoke flue diameter 150 mm
External air intake diameter 150 mm
Draught 10 Pa
Efficiency 80,3 %
Average wood consumption 2,7 kg/h
A+
