HEAT W 2g 70.50.01 - fireplace insert with hot-water exchanger
New
Water exchanger Front Steel–cast iron combination Hot air (conventional) Triple pass
To:
From:
Message:
Security verification: (Display a new code)
Enter a code
  up

HEAT W 2g 70.50.01 - fireplace insert with hot-water exchanger

•  Romotop HEAT W 2g 70.50.01 fireplace insert with hot-water exchanger
•  hot-water exchanger with the patented TRIPLE PASS system

•  CAI (central air intake)
•  exchanger volume of 61 l
•  a cleaning hole for easy access to clean the exchanger
•  built-in aftercooling loop
•  cast iron grate
•  ash pan
•  chamotte combustion chamber
•  adjustable legs
•  glass with printed decor
•  door frame made of special rigid rolled profile
•  the fireplace insert includes an air-outlet valve
•  build-up dimensions: 699 x 498 mm
•  construction frame may be added
•  log length 500 mm
•  complies with the following standards: EN 13 229, DIN+, Bimsch V 1/2, Czech Republic Clean Air Act
•  order code: HW2Z 01

Prices on request at your seller.


Accessory approved by the manufacturer:

Technical parameters

Height 1200 mm
Width 800 mm
Depth 553 mm
Weight 245 kg
Regulated output 7.0-19.0 kW
Regulated output of water exchanger 5.0-13.5 kW
Smoke flue diameter 180 mm
Central air intake diameter 150 mm
Draught 12 Pa
Efficiency 89 %
Average wood consumption 4 kg/h
