NAVIA 01 ceramic - fireplace stove

order code: NAVIA 01

“The sensitive fusion of all major stove dimensions has resulted in a unique design. The rounded and unique dimensions of the glass provide a large area for direct observation of the flames.”

•  suitable for low-energy houses
•  massive cast-iron grate at the bottom of the furnace for up to 50 cm logs
•  pleasant, ergonomically shaped door handle
•  preheating of the secondary air to keep the glass clean
•  popular elliptical base
•  cleanly integrated door of wood storage area
•  air regulation with only one control
•  resistant chamotte lining of the furnace
•  three-point door closure ensures stove tightness even at a lower draft
•  ready for an external connection of the combustion air intake (EAI)

Low-energy buildings External air intake

Technical parameters

Height 862 mm
Width 787 mm
Depth 374 mm
Door height 588 mm
Door width 644 mm
Door depth 87 mm
Weight 164 kg
Regulated output 3,0-7,8 kW
Smoke flue diameter 150 mm
Flue socket diameter 150 mm
External air intake diameter 125 mm
Axis height of rear outlet 729 mm
Draught 11 Pa
Efficiency 83,5 %
Average wood consumption 1,6 kg/h
